DTH Hammer Blast Hole Drill Rigs Crawler Mounted Open Air Split Type

1 Set
MOQ
DTH Hammer Blast Hole Drill Rigs Crawler Mounted Open Air Split Type
Features Gallery Product Description Request A Quote
Features
Specifications
Name: DTH Hammer Blast Hole Drill Rigs Crawler Mounted Open Air Split Type
Engine Power: 50 KW
Drilling Depth: 15-20m
Propulsion Mode: Cylinder Chain
Highlight:

Hammer Blast Hole Drill Rigs

,

DTH Blast Hole Drill Rigs

,

Crawler Mounted DTH Drill Rigs
Basic Infomation
Place of Origin: Hebei,China
Brand Name: Aoxing
Certification: ISO9001
Model Number: ZGYX-415
Payment & Shipping Terms
Packaging Details: in Plywood Case
Supply Ability: 30 Sets/Month
Product Description

Crawler Mounted DTH Hammer Blasting Hole Drill Rigs



Product Description

ZGYX-415 open-air split-type deep hole drilling machine is another high-performance research and development of mining industry cost-effective rig products. 415 model drilling rig is in a large number of ZGYX-410E drill rig users to use the report, the drilling rig components, hydraulic systems, propulsion beam, rotary head, the whole body to upgrade and optimize. The upgraded drilling rig has the advantages of strong climbing ability, large turning torque and long motor life, and it is suitable for the open mining environment under various conditions.
ZGYX-415 crawler mounted DTH drilling rig technical figures
Rig model ZGYX-415
Diesel engine model Yuchai YCD4R12T-70
Engine power 50 KW
Drilling depth 15-20m
Drilling diameter Φ90-Φ127mm
Working air pressure 0.8-1.45 MPa
Air consumption 7-13 m3/min
Drilling pipe diameter Φ60,Φ76
Length of drill pipe 3.0m
One push length 3.0m
Tramming speed 2.5km/h
Climbing ability (Max.) 25°
Ground clearance (Min.) 250mm
Rotation speed 0-110 rpm
Rotation torque 1850 N.m
Propulsion 15KN
Lifting capacity 250KN
Propulsion mode Cylinder chain
Weight 4500kg
Transportation dimension 5500x2000x2100mm



DTH Hammer Blast Hole Drill Rigs Crawler Mounted Open Air Split Type 0DTH Hammer Blast Hole Drill Rigs Crawler Mounted Open Air Split Type 1DTH Hammer Blast Hole Drill Rigs Crawler Mounted Open Air Split Type 2DTH Hammer Blast Hole Drill Rigs Crawler Mounted Open Air Split Type 3DTH Hammer Blast Hole Drill Rigs Crawler Mounted Open Air Split Type 4
