Home /Products/Core Bits/T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height

T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height

1 Piece
MOQ
T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height
Features Gallery Product Description Request A Quote
Features
Specifications
Model NO.: T256 66 76 86 101
Type: Core Drill Bit
Material: Diamond
Usage: Exploration, Mining Drill
Matrix Height: 6mm-12mm
Shape: Round
Manufacturing Arts: Sinter
Kind: Diamond Drill
Specification: DCDMA, CDDA, BS
Origin: China
Highlight:

Double Tube Core Drill Bit

,

T6 Series Core Drill Bit

,

12mm Matrix Height Drill Bit
Basic Infomation
Place of Origin: Hebei,China
Brand Name: Aoxing
Certification: ISO9001
Model Number: T256 66 76 86 101
Payment & Shipping Terms
Packaging Details: in Plywood Case
Product Description




T6 Series Double Tube Core Drill Bit:

T Series Bit





No. Std. Item OD*ID(mm) Crown Height SN.
1 T2-46 diamond bit 46.0*31.7 C6 K3 K5 K7 K9
2 T2-56 diamond bit 56.0*41.7 C6 K3 K5 K7 K9
3 T2-66 diamond bit 66.0*51.7 C6 K3 K5 K7 K9
4 T2-76 diamond bit 76.0*61.7 C6 K3 K5 K7 K9
5 T2-86 diamond bit 86.0*71.7 C6 K3 K5 K7 K9
6 T2-101 diamond bit 101.0*83.7 C6 K3 K5 K7 K9
7 T6-76 diamond bit 76.0*57.0 C6 C9 K3 K5 K7 K9
8 T6-86 diamond bit 86.0*67.0 C6 C9 K3 K5 K7 K9
9 T6-101 diamond bit 101.0*79.0 C6 C9 K3 K5 K7 K9
10 T6-116 diamond bit 116.0*93.0 C6 C9 K3 K5 K7 K9
11 T6-131 diamond bit 131.0*108.0 C6 C9 K3 K5 K7 K9
12 T6-146 diamond bit 146.0*123.0 C6 C9 K3 K5 K7 K9
13 T6S-76 diamond bit 76.3*47.7 C6 C9 K3 K5 K7 K9
14* T6S-86 diamond bit 86.3*57.7 C6 C9 K3 K5 K7 K9
15 T6S-101 diamond bit 101.3*71.7 C6 C9 K3 K5 K7 K9
16 T6S-116 diamond bit 116.3*85.7 C6 C9 K3 K5 K7 K9
17 T6S-131 diamond bit 131.3*100.7 C6 C9 K3 K5 K7 K9
18 T36 diamond bit 36.0*21.7 C6 K3 K5 K7 K9
19 TT46 diamond bit 46.0*35.2 C6 K3 K5 K7 K9
20 TT56 diamond bit 56.0*45.2 C6 K3 K5 K7 K9

T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height 0T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height 1T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height 2T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height 3

T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height 4T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height 5T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height 6T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height 7

T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height 8T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height 9T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height 10T6 Series Double Tube Core Drill Bit with 6mm-12mm Matrix Height 11
