Specifications of XY-100 hydralic core drilling rig
| Model |
XY-100 |
| Drilling depth |
110 |
| Maximum open hole caliber |
220mm |
| End hole caliber |
75mm |
| Drill rod caliber |
50mm /42mm |
| Drilling angle |
90 |
| Drilling rig weight (exclude diesel engine) |
610kg |
| Unity machine dimensions |
2.1*0.9*1.3m |
| Spindle |
| Spindle speed |
130/300/480/730/830/1045 r/min |
| Spindle stroke |
450mm |
| Hoist |
| Max. lifting capacity with single rope |
1600kg |
| Lifting speed with single rope |
1.06/0.67/0.32 m/s |
| Wire rope caliber |
13mm |
| Wire rope cubic measure |
35mm |
| Hug floodgate caliber |
254mm |
| Hug floodgate belt width |
50mm |
| Distance between drill and hole |
230mm |
| Mud pump |
| Type |
Horizontal single-urn twin-action |
| Displacement (with diesel engine/electric motor) |
170l/min |
| Max. pressure |
1.5mpa |
| Work pressure |
0.7mpa |
| Power |
| Diesel engine |
S1100 |
| Electric motor |
Y160M-4 / 10KW |
Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.
Parameters of XY-150 hydraulic core drilling rig
| Model |
XY-150 |
| Drilling depth(m) |
150 |
| Maximum opening diameter(mm) |
219 |
| The final hole diameter(mm) |
73 |
| Rod diameter(mm) |
42/50 |
| Spindle speed (r/min) |
140/295/470/790/1010 |
| Spindle stroke(mm) |
450 |
| Hoisting capacity (kn) |
14 |
| Steel wire diameter(mm) |
9.3 |
| Maximum pressure (mpa) |
1.2 |
| Working pressure (mpa) |
0.7 |
| displacement(l/min) |
150 |
| Hydraulic pump pressure (mpa) |
1.2 |
| Hydraulic pump rotation speed (r/min) |
1800 |
| Matched driving power (diesel engine and motor) |
S1105 diesel engine and 11kw motor |
Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.
Hengshui Aoxing Geological Equipment Co., Ltd. has over 10 years of market experience and is a manufacturer and supplier of grouting materials and drilling materials in the fields of water conservancy, geology, mining, tunnels, subways, construction, geological exploration, mining exploration, geotechnical engineering, soil investigation, etc.
The main products include: inflatable or water filled packer, manual packer, high-pressure grouting pipe, pneumatic hose, FULO grouting pipe, sleeve valve grouting pipe, grouting data acquisition instrument, grouting pump, screw grouting pump, cement mixer, high-speed grouting machine, mud station, spray, Lurong test packer and Lurong test equipment, diamond bit, reamer, geological drill pipe and casing, hydraulic drill, core drill, geological drill, exploration drill, soil testing and investigation drill, full hydraulic drill, module drill, portable drill, water well drill, engineering drill, mechanical top drive drill, small drill, DHT drill, air compressor, core barrel, fishing bucket, SP T tools, soil sampling tools, drilling tools and accessories, grouting pump accessories and drilling rig accessories, etc.
Our team is dedicated to dam curtain consolidation grouting, foundation engineering grouting, mineral exploration, soil investigation, and geological engineering. Provide solutions for engineering drilling.
We can provide accurate, valuable, and targeted solutions and services to our customers based on their specific requirements and needs.
