Wireline Geological Drill Rod For Mining Exploration BQ NQ HQ PQ

1 Piece
MOQ
Wireline Geological Drill Rod For Mining Exploration BQ NQ HQ PQ
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Wireline Geological Drill Rod For Mining Exploration BQ NQ HQ PQ
Size: BQ NQ HQ PQ
Aplication: Mining Exploration
Type: Geological Drill Rod
Highlight:

Wireline Geological Drill Rod

,

Mining Exploration Geological Drill Rod

,

BQ Geological Drill Rod

Basic Infomation
Place of Origin: Hebei,China
Brand Name: Aoxing
Certification: ISO9001
Model Number: BQ NQ HQ PQ
Payment & Shipping Terms
Packaging Details: in Plywood Case
Supply Ability: 500Sets/Month
Product Description

Wireline Geological Drill Rod For Mining Exploration (BQ NQ HQ PQ)

Product Description

1. Our wireline drill rods are all manufactured by CNC machines under DCDMA standard. They're made of high quality alloy steel with heat-treated. We also can produce various sizes of casing tubes.

2. Drill pipes will be manufactured from seamless steel tube by cold drawn. The material is XJY850/30CrMnSiA which is one of the best material for geological drilling in China.

3. Coring rods are crafted from quality heat treated materials ensuring superior wear resistance, strength, and toughness in the most demanding applications.

4. Rods and casing are manufactured under stringent industry standards, and are field tested under a variety of conditions.

5. All rods are designed to be compatible with other rods manufactured to DCDMA

Product Parameters

Drill Rod:

Size Outer Diameter (mm) Inner Diameter(mm)
AQ 44.7 37.3
BQ 55.7 46.1
NQ 70.0 60.2
HQ 89.0 78.0
PQ(PHD) 114.5 101.5
BTW 56.3 48.0
NTW 73.3 64.0
HTW 91.3 81.0
AW/AWJ/AWY 43.7 30.7
BW/BWJ/BWY 54.0 38.0
NW/NWY 66.8 51.0
HW 89.0 71.0
42mm 42.0 30.0
50mm 50.0 37.0
60mm 60.0 48.0
70mm 73.0 54.6
90mm 89.0 69.0
S75A 71.0 60.0
S95A 89.0 78.0
S110 110.0 98.0
S130 129.0 117.0

Casing Tubes:

We also can produce various sizes of casing tubes
Size Available:
"W" Design: RW, EW, AW, BW, NW, HW, PW, SW, UW, ZW, HWT,PWT
Metric Series: 46, 56, 66, 76, 86, 101, 116, 131, 146
"X" Design: RX, EX, AX, BX, NX, HX, PX, SX, UX, ZX
