Rock Crawler Blast Hole DTH Drill Rig 20m Drill Hole Depth For Mine

Rock Crawler Blast Hole DTH Drill Rig 20m Drill Hole Depth For Mine
Features Gallery Product Description Request A Quote
Features
Specifications
Model NO.: HW938
Motor: Diesel Engine
Drill Hole Diameter: 90-138mm
Drill Hole Depth: 20m
Bit Type: Diamond Bit
Drilling Way: Rotary
Dimension: 7550*2500*3060
Drill Diameter: 110-138 Mm
Power (Kw): 191
Maximum Working Torque (N.M): 2500
Rotation Speed (Rpm): 0-100
Propulsion (Kn): 20
Lifting Force (Kn): 45
Highlight:

DTH Blast Hole Drill Rig

,

Crawler DTH Drill Rig

,

Crawler Blast Hole Drill Rig
Basic Infomation
Place of Origin: China
Brand Name: Aoxing
Certification: ISO9001
Model Number: HW938
Payment & Shipping Terms
Product Description



Rock Dht Crawler Blast Hole Drill Rig for Mine



The down-the-hole drilling rig uses the impactor and drill bit that dive into the bottom of the hole to impact and crush the rock, so it is called a down-the-hole drilling rig. Widely used in metal mines, hydropower, transportation, building materials, harbors and engineering. Down-the-hole drilling rigs can drill holes in rocks with medium hardness or above (f≥8). The price of drilling rigs is relatively cheap, especially suitable for small and medium-sized open pit mines.





Model HW938
Engine YUCHAI
Power (KW) 191
Drilling diameter (mm) φ90-138
Maximum working torque (N.m) 2500
Rotation speed (rpm) 0-100
Propulsion (kN) 20
Lifting force (kN) 45
Walking speed (km/h) 3
Shipping Dimensions (mm) 7550*2500*3060
Dust collection method /



Rock Crawler Blast Hole DTH Drill Rig 20m Drill Hole Depth For Mine 0Rock Crawler Blast Hole DTH Drill Rig 20m Drill Hole Depth For Mine 1Rock Crawler Blast Hole DTH Drill Rig 20m Drill Hole Depth For Mine 0Rock Crawler Blast Hole DTH Drill Rig 20m Drill Hole Depth For Mine 3
