Mining Exploration Wireline Drilling AQ BQ NQ HQ PQ Impregnated Diamond Core Bits Geological Drill Bit

Mining Exploration Wireline Drilling AQ BQ NQ HQ PQ Impregnated Diamond Core Bits Geological Drill Bit

Diamond core bits products include: 1,drill bit: Impregnated diamond diamond drill bit, sufface set diamond drill bit, electroplated diamond drill bit, tc drill bit, PCD drill bit, thin wall drill bit; Hole: alloy reamer, polycrystalline reamer, electroplated reamer,surface set natural diamond reamer;

The impreqnated diamond bits have the widest range of application. They are the most commonly useful bits from medium to super hard formations in the mineral exploration industry, the Hardness and abrasive of the rock formation are the key factors to determine the diamond specifications,concentration and matrix hatdnesS. Toothed bits can get higher drilling efficiency when it is drilling at dense or abrasive stratum with lower drilling speed and pressure.It was especially effective at coal formation, using toothed bits can get better water flowing and drling footage effect. Nowadays, Impregnated diamond bits have been widely used in wire-line drilling series.

The impreqnated diamond bits have the widest range of application. They are the most commonly useful bits from medium to super hard formations in the mineral exploration industry, the Hardness and abrasive of the rock formation are the key factors to determine the diamond specifications,concentration and matrix hatdnesS. Toothed bits can get higher drilling efficiency when it is drilling at dense or abrasive stratum with lower drilling speed and pressure.It was especially effective at coal formation, using toothed bits can get better water flowing and drling footage effect. Nowadays, Impregnated diamond bits have been widely used in wire-line drilling series.

Parameter of Diamond Core Bit:

Drill Bit Selection Reference Table:

Diamond Drill Bit Lip Shape:

Full Round		Higher diamond content in the bit face.higher penetration rate.and suitable for drilling hard rocks.
Semi-round		Even diamond distribution in the bit face,suitable for drilling medium-hard and hard rocks.or a little broken and loose formations.
Fiat		For impregnated diamond bit oniy,suitable for drilling hard abrasive rocks.
Bottom Discharge Design		Suitable for drilling sedimentary or metamorphic formations containing more powder mineraiw with high core recovery percentage,and no excessive core washout.
Stepped		Suitable for dr drilling medium-hard,broken or interbedded formations, hoie deviation can be prevented.
Tapered		Suitable for drilling soft and medium-hard formations with high penetration rate.
Serrated Profile		Suitable for drilling hard dense formations with high penetration rate.
Staggered Concentric Profile		Suitabie for drilling hard dense formations with high penetration rate under low bit weight.
GearWheel		Suitabie for drilling hard dense formations with high penetration rate.
